비트메인 Antminer S23 Hyd 3U 비트코인 채굴기 – 1160 TH/s, 9.5 J/TH

Antminer S23 Hyd 3U — 1.16 PH/s in a Single Miner

Antminer S23 Hyd 3U is a Bitmain SHA-256 ASIC miner with a typical hashrate of 1,160 TH/s. Identified by model code U3S23H, this configuration combines hydro cooling, a 3U chassis and specified power efficiency of 9.5 J/TH at 35°C.

It is intended for professional mining installations with electrical and cooling infrastructure capable of supporting an 11.02 kW miner load.

1,160 TH/s for High-Capacity Deployments

A single S23 Hyd 3U provides 1.16 PH/s of typical hashrate. For operators planning fleet expansion, this provides a clear basis for calculating machine quantities and infrastructure requirements.

Ten units represent 11.6 PH/s of typical hashrate and 110.2 kW of specified miner wall power, excluding separately powered cooling equipment and other site loads.

9.5 J/TH Power Efficiency

At the specified operating point, the S23 Hyd 3U uses 9.5 joules per terahash. This figure helps operators compare energy requirements across SHA-256 mining hardware.

Compared with the S21e XP Hyd 3U 860 TH/s configuration listed at 13 J/TH, the supplied specifications indicate approximately:

• 34.9% higher hashrate per unit
• 26.9% lower energy consumption per terahash
• 1.4% lower wall power per unit

These comparisons use the listed specifications at 35°C. They describe hardware performance, rather than guaranteed improvements in mining profit.

S23 Hyd 3U vs. S21e XP Hyd 3U

For buyers comparing these configurations, the S23 Hyd 3U delivers more specified hashrate while drawing slightly less miner wall power.

Hydro Cooling for Professional Mining Sites

The S23 Hyd 3U transfers heat through a liquid-cooling circuit. A compatible external cooling system is required to maintain the operating conditions specified for the equipment.

Before deployment, confirm coolant requirements, inlet temperature, flow rate, pressure and connection specifications for the exact unit. Cooling capacity should be planned around the total installation load.

3U Format for Rack-Based Installations

The 3U format supports organized rack-based mining layouts. Installation planning should account for mounting compatibility, electrical distribution, water connections, cable routing and maintenance access.

The number of miners per rack depends on available power, cooling capacity, structural limits and service clearances.

SHA-256 Mining for BTC, BCH and BSV

The Antminer S23 Hyd 3U supports the SHA-256 algorithm used by Bitcoin, Bitcoin Cash and Bitcoin SV.

Mining configuration depends on the selected network, compatible firmware and pool settings. The supported coin list does not mean the miner automatically earns rewards from all three networks simultaneously.

Technical Specifications

Specifications refer to the listed 1,160 TH/s configuration. Actual operating performance depends on equipment configuration and installation conditions.

Electricity Consumption

At a constant wall power of 11.02 kW, calculated electricity consumption is:

Estimated daily miner electricity cost = 264.48 × electricity price per kWh.

These calculations exclude separately powered pumps, cooling equipment and other facility loads. Use total site consumption when preparing an operating budget.

Frequently Asked Questions

What is the Antminer S23 Hyd 3U?

The Antminer S23 Hyd 3U is a Bitmain hydro-cooled SHA-256 miner. The U3S23H configuration listed here delivers a typical hashrate of 1,160 TH/s with specified wall power consumption of 11,020W at 35°C.

Is 1,160 TH/s the same as 1.16 PH/s?

Yes. One petahash per second equals 1,000 terahashes per second, so 1,160 TH/s equals 1.16 PH/s.

What is the power efficiency of this model?

Its specified wall power efficiency is 9.5 J/TH at 35°C. This expresses the energy consumed per terahash of hashing work.

How does it compare with the S21e XP Hyd 3U 860T?

Based on the listed configurations, the S23 Hyd 3U offers approximately 34.9% more hashrate and 26.9% lower energy consumption per terahash. Its specified wall power is 11,020W, compared with 11,180W for the 860T model.

Which coins can it mine?

It supports SHA-256 mining for BTC, BCH and BSV through compatible mining configurations. It does not support Scrypt mining for Litecoin or Dogecoin.

Does it need an external cooling system?

Yes. A compatible liquid-cooling system is required. Confirm the exact cooling requirements and supplied accessories before installation.

What electrical supply does it require?

Electrical installation must match the exact unit’s input voltage, phase configuration, connectors and current requirements. With a specified miner load of 11.02 kW, site power compatibility should be confirmed before ordering.

What is included with the miner?

Package contents depend on the quotation. Contact PunkHash to confirm power equipment, cables, cooling fittings, shipping details and applicable warranty terms.

Order the Antminer S23 Hyd 3U from PunkHash

PunkHash supplies ASIC mining hardware and supports customers with product selection, sourcing and technical enquiries.

For a quotation, please provide:

• Required model and quantity.
• Delivery country and postcode.
• Available electrical capacity.
• Existing or planned cooling infrastructure.

Our team will help clarify the equipment configuration, supply scope and delivery options for your project.
